With the bolt connector set complete, stable right-angled connections of two profiles are created. In one profile a through hole D17 must be drilled 22.5mm from the outer edge.
In addition to two screws and hammer nuts, the kit includes a centering pin and two cover plates.
Can be installed with all profiles of series 10 in grid 90
Technical data
Material: PA, ST galvanised
Weight kg/set: 0,161
